Product Description
The plunger valve is a globe-body throttling valve for precise flow regulation and energy dissipation in pipeline systems. The streamlined plunger element provides a characterised flow curve, making it suitable for constant throttling duty where butterfly and gate valves would suffer cavitation or excessive wear. Used downstream of pressure reducing stations, at reservoir inlets and for turbine bypass on hydroelectric schemes.
Specifications
Size rangeDN50–DN600
PressurePN16 / PN25
MaterialDuctile iron body, rubber-lined plunger, stainless stem
ConnectionFlanged to EN 1092-2
Approvals & Certifications
ISO 9001International quality management system certification
Standards
EN 1074-5
Typical Applications
- Energy dissipation
- Reservoir inlet regulation
- Throttling service
- Turbine bypass
Request a Quote
Send us your size, pressure rating and quantity and we will respond with pricing and full technical documentation, typically within one working day.
Request a Quote or email info@afcvalves.euAt a glance
- Sizes
- DN50–DN600
- Pressure
- PN16 / PN25
- Connection
- Flanged to EN 1092-2
